• Industrial cast iron machine frame for vibration free operation
• (5) working units to produce a wide range of tenons and profiles for door, window components, and furniture parts
• Accurate adjustment using mechanical digital readouts
• Spiral insert knife tenon cutterheads with scriber tips for superior tenoning results
• Opposed coping heads allow for profiling even with long tenons
• Vertical and horizontal pneumatic workpiece clamping ensures material is secure during tenoning operation
• Infeed and outfeed safety guards
• Sliding table rolls on precision machined ” V ” ways allowing for precise and smooth table movement
• Mechanical stops for precision length cutting
• Adjustable infeed fence determines stock removal length
• Dust extraction ports on each working unit
• Schneider electrical components to CSA standard

Trim Saw

• 12” dia. driven from tenon heads
• 1 ¼” shaft diameter x 6″ long
• 2800 RPM
• Saw position moved by changing spacers

Tenon Heads

• Carbide insert spiral tenon heads with scribing inserts
• 152mm (6”) long x 127mm (5”) diameter tenons heads
• 5HP motor drives both tenon heads
• 1 ¼” diameter spindle
• 3400 RPM
• 1″ lateral adjustment of tenon heads
• 14 mm x 14mm x 1.5mm carbide insert knives

Coping Heads

• Max. dia. tooling: 6 3/8”
• (2) 5 HP motors
• 1 ¼” diameter spindle
• 6000 RPM
• 2 ¾” spindle length
• Independent adjustment each head
• (2) 4 knife wedge type cutterheads with chip breakers included (60^o corrugated knives)
• Counterbore locknut allows both heads to move close together
