· Cast iron ground & polished table with insert rings

· Precision ground and electronically balanced spindle

· V-belt drive with 5 feed speeds is easily accessed from the front of the machine

· Electric spindle brake for added safety

· Spindle lock - with limit switch safety, machine will not start with lock engaged

· Micro spindle height adjustment with dial indicator

· Interchangeable cutter spindle

· Forward/reverse spindle rotation

· Adjustable "finger" type fence

· Independent micro-fence adjustment on both sides

· Includes the following standard equipment: 1 ¼" spindle, dust connection chute, safety guard, tenon jig, and Telemecanique magnetic controls

Table size 31 ½” x 39.4”

Spindle speeds (5) 3000/4000/6000/8000/10000 RPM

Spindle taper 5 MT

Spindle diameter 1 ¼"

Motor 7.5 HP

Largest diameter of cutter:

Above table 8 ¼”

Below table 13 ¼”

Fence size 6” x 43”

Vertical spindle stroke 7”

Useable length of spindle 5 ½” long

Electrics 230/3/60 = 22 Full Load Amps

Dust port (1) 5”

Total HP 7.5 HP

Net weight 1034 lbs.

Machine dimensions 48.4” x 39.4” x 52 ¾”

Shipping weight 1166 lbs.

Shipping dimensions 45 ¼” x 37” x 41”
