2022 SCM Stefani KD ERT Edgebander - Florida
Couldn't load pickup availability
Interested in this Machine?
Call (888) 375-0384 or Click Here to Email Us at info@ibidmachinery.com
2022 SCM Stefani KD ERT Edgebander in Tampa, Florida
Like New Condition
Needs to Move out FAST.
Why is owner selling?: The owner has a shop in Canada and he and his partner were going to open a new shop and Florida and decided to not to open the shop. Machines are in like new condition - never used!
Technical Specifications
|
Glue Pot Unit: |
|
|
Heating Time |
Approx. 8-10 min. |
|
Glue Capacity |
3.3 lbs. |
|
Pre-milling Station: |
|
|
Horsepower |
3.0 HP ea. |
|
RPM |
12,000 RPM |
|
Max. Stock Removal |
60mm² |
|
Diameter/Bore/Height |
100mm/30mm/45mm |
|
End Cutting Trimming Station: |
|
|
Horsepower |
.50 HP ea. |
|
RPM |
12,000 RPM |
|
Tilting |
0-15 degrees |
|
Blade Diameter/Bore |
100mm/32mm |
|
Tiltable Edge Trimming Unit: |
|
|
Horsepower |
1.0 HP ea. |
|
RPM |
12,000 RPM |
|
Tilting |
0-15 degrees |
|
Cutting Tools |
70x20x16mm |
|
|
3mm radius knives |
|
Corner Rounding Unit:: |
|
|
Horsepower |
.80 HP ea. |
|
RPM |
12,000 RPM |
|
Cutting Tools |
3mm inserts |
|
Scraping Unit: |
|
|
Knife Radius |
3mm inserts |
|
Buffing Unit:: |
|
|
Horsepower |
.25 HP |
|
RPM |
3,000 RPM |
|
Diameter/Bore |
152mm/17mm |
|
Feed Motor Horsepower |
2.5 HP |
|
Feed Speed |
33-60 FPM |
|
Frequency Converter |
200 Hz |
|
Pneumatic Operating Pressure |
90 PSI |
|
Machine weight: |
6,206lbs. |
|
Electrical: |
67 amps @ 230v three phase |
|
Dust: |
3,250 cfm |
|
Dimensions (LxWxH): |
229” x 65” x 62” (add 45” for air flotation table) |
*MACHINE SOLD AS IS WHERE IS WITH NO IMPLIED WARRANTY* Information displayed has been gathered from machine owner, internet searches and other sources. Information is believed to be correct, but not guaranteed. All buyers should verify this information independently and/or have the machine inspected for accuracy prior to purchase*
Product Description:
Machine Location State: Florida
Machine Location City: Tampa
Year: 2022
Make: SCM Stefani
Model: KD ERT
Serial No:
Phase/Voltage: 3 ph/230 v
Condition: Excellent - Like New
Any Known Issues: None - like new condition
In Production: No
Software Transfer:
Access to Forklift for Loading:
Loading Fee:
Shipping Dimensions: 229” x 65” x 62” (add 45” for air flotation table)
Shipping Weight: 6372 lbs approx
Shipping Brackets Available:
